SN5200 overview and datasheet

Looking for a complete, modular and scalable network security solution for your critical infrastructures? The SN-XL-Series-5200 NGFW firewall not only offers very high performance for your network protection, but also gives you peace of mind when it comes to service continuity, thanks to its high availability and redundant power supply and ventilation. This all-in-one security appliance provides effective management of WAN and SD-WAN links, as well as secure remote connections thanks to VPN and ZTNA functionalities. Network expansion capabilities, modularity between copper and fibre interfaces, high port density: the SN-XL-Series-5200's scalable performance and network modularity are the perfect match for the evolution of your critical information infrastructures. Cyber-serenity is yours.

239.8 Gbps
FIREWALL
performance

43.5 Gbps
VPN IPSEC
performance

10.8 Gbps
ANTIVIRUS
performance

SN5200 demo

Want to know more about our NGFW SN5200 firewall before you make your decision? Just click on the link and get in touch with our sales team. They will help you to access our demonstration environment and to manipulate the product firmware.

Technical information of the SN5200

Technical specifications

Performance

Firewall (1518 bytes UDP)

239.8 Gbps

Firewall (IMIX)

64.7 Gbps

IPS (1518 bytes UDP)

93.1 Gbps

IPS (IMIX)

24.9 Gpbs

Threat Prevention (Firewall, IPS, antivirus, IP Reputation, webservice, with logging enabled)

10.8 Gbps

VPN

IPSec - AES-GCM (1408 bytes)

43.5 Gbps

IPSec - AES-GCM (IMIX)

21.6 Gbps

Max number of IPSec VPN tunnels (1024kbps per tunnel)

20,000

Number of simultaneous SSL VPN clients

5,000

Network Connectivity

Max number of simultaneous sessions

15,000,000

Connectivity

2.5GBASE-T copper interfaces

2-64

10GBASE-T copper interfaces

0-32

1Gb SFP interfaces

0-62

10Gb SFP+ interfaces

0-32

40Gb QSFP+ interfaces

0-16

Optional network extension modules

8

Redundancy

Redundant SSD

✓

Redundant power supply

✓ (hot swappable)

Redundant ventilation (hot swappable)

✓

Hardware

Log storage

480 GB SSD (hot swappable - RAID 1)

Optional storage for log (Big Data option)

960 GB SSD (option Big Data - RAID 1)

Height x Width x Depth (mm)

88.9 x 443 x 650

Weight

18.97 kg (41.82 lbs)

Performance is measured in a laboratory and under ideal conditions. Results may vary according to test conditions and software version.

Compare this product with

Looking for more technical specifications about our SN5200 firewall? Find the full technical specifications on the SN5200 datasheet, as well as a more complete list of available features.

SN-XL-Series-5200

A network security solution, qualified by the ANSSI in France, for modularity and high performance for your critical infrastructures

Associated services to the SN5200

Stormshield supports you step by step, according to your cybersecurity needs and maturity level.

Documentation

Access all SN5200 technical documentation, including installation guides, user guides, technical notes and release notes.

Firmware

Having the latest firmware version ensures you're up to date in terms of new features and patches. Some major releases also deliver performance enhancements for the SN5200 firewall. Explore the latest developments in the new version, including enhanced protection, easier management and new features.

Management tools

Get maximum security and effective protection with our complementary centralised management and log management solutions.

Training

Learn how to integrate, configure and monitor our products with our high-level certification training.

Maintenance

Our service and security packages extend the products’ hardware warranty to provide you with continuous updates for protection systems.

Technical support

In France and abroad, our technical teams are always close at hand to ensure the security of your software and hardware infrastructure, giving you guaranteed continuity of service.

Trial version and pricing of the SN5200

Designed for large organisations, large enterprises and government departments, the SN-XL-Series-5200 firewall meets the challenges of modularity, scalability and secure connectivity for critical infrastructures - thanks in particular to its high port density. The SN-XL-Series-5200 shares a common enclosure and a scalable software platform with the SN-XL-Series-6200 that can be adapted to your growth needs by simply purchasing a licence.

Would you like to try out the firmware in our SN5200 european firewall? Our teams are ready and waiting to discuss projects, arrange an appointment or handle any other request.

Scalability through
software options

Adaptability
and modularity

High density
of ports

Secure remote
connections
