Are you looking for a complete network security solution? The SN-M-Series-520 firewall offers advanced network features such as antivirus, antispam, IPS, web/URL filtering, IPsec VPN, SSL VPN, and redundant power supply. You can also take advantage of SD-WAN features for trusted WAN and central site connections.
Cyber-secure your business with a security solution that seamlessly adapts to your infrastructure without impact.
Qualification
STANDARD
by the ANSSI (FR)
SN520 demo
Want to know more about our SN520 firewall before you make your decision? Just click on the link and get in touch with our sales team. They will help you to access our demonstration environment and to manipulate the product firmware.
SN520 technical information
Technical specifications
Performance
Firewall throughput (1518 byte UDP)
10 Gbps
Firewall (IMIX)
7 Gbps
IPS throughput (1518 byte UDP)
5 Gbps
Threat Prevention throughput (Antivirus HTTP)
1.3 Gbps
VPN
IPSec throughput - AES-GCM
2.5 Gbps
Max number of IPSec VPN tunnels
1,000
Number of simultaneous SSL VPN clients
150
Network Connectivity
Concurrent connections
600,000
Connectivity
1000BASE-T copper interfaces
0-8
2.5GBASE-T copper interfaces
8-16
10GBASE-T copper interfaces
0-4
1Gb SFP interfaces
2-10
10Gb SFP+ interfaces
0-4
Bypass pairs (on copper ports)
0-4 (optional network module)
Optional network extension modules
1
Redundancy
Redundant power supply
✓
Hardware
Log storage
> 200 GB SSD
Height x Width x Depth (mm)
44.45 x 440 x 360
Weight
4.17 kg (9.19lbs)
Performance is measured in a laboratory and under ideal conditions. Results may vary according to test conditions and software version.
Looking for more technical specifications about our SN520 firewall? Find the full technical specifications on the SN520 datasheet, as well as a more complete list of available features.
SN-M-Series-520
A network security solution, qualified by the ANSSI in France, to boost your business connectivity
SN520 associated services
Stormshield supports you step by step, according to your cybersecurity needs and maturity level.
Documentation
Access all SN520 technical documentation, including installation guides, user guides, technical notes and release notes.
Firmware
Having the latest firmware version ensures you're up to date in terms of new features and patches. Some major releases also deliver performance enhancements for the SN520 firewall. Explore the latest developments in the new version, including enhanced protection, easier management and new features.
Management tools
Get maximum security and effective protection with our complementary centralised management and log management solutions.
Training
Learn how to integrate, configure and monitor our products with our high-level certification training.
Maintenance
Our service and security packages extend the products’ hardware warranty to provide you with continuous updates for protection systems.
Technical support
In France and abroad, our technical teams are always close at hand to ensure the security of your software and hardware infrastructure, giving you guaranteed continuity of service.
SN520 trial version and pricing
The SN-M-Series-520 firewall is designed for mid-sized organisations to meet connectivity and security needs. Benefit from a wide range of features for unified security as well as a perfect response to European data protection standards (RGPD).
Would you like to try out the firmware in our SN520 European Firewall? Our teams are ready and waiting to discuss projects, arrange an appointment or handle any other request.
